Stone Pickers
5ft Utility Pull Type -
Call us today for details!
AFE now offers a Utility 5ft Pull Type Stone Picker. Each Stone Picker comes standard with a Holding Bin for "on the go" field storage making disposal of stones easier.
5ft Stone Picker
Utility 5ft Pull Type Stone Picker Dimensions
Length: 22.75ft*
Height: 5.375ft
Digger Width: 5ft
Overall Width: 8ft
Bin Capacity: 1.6 Cubic Yards
*changes if conveyor is added on
Utility 5ft Pull Type Stone Picker Chain
Different chain options available. Call for details.
Utility 5ft Pull Type Stone
Picker Options
-
Unloading Conveyor
-
Sand Pans
-
Trailer Jack Kit
-
Gauge Wheels
-
Rock Traps
Call for details.
Utility 5ft Pull Type Stone Picker Features
Recommended Tractor Specifications:
-
80-120 Horsepower
-
15 GPM Hydraulic Flow
Key Features:
-
Fully Hydraulic
-
Instant Reversing
-
Cat 2 Hitch
5ft Standard Pull Type -
Call us today for details!
AFE offers a Standard 5ft Pull Type Stone Picker for optimal stone removal.
Standard 5ft Pull Type Stone Picker Dimensions
Standard 5ft Pull Type Stone Picker Chain
5ft Pull Type Stone
Picker Options
Different chain options available. Call for details.
-
Unloading Conveyor
-
Hydraulic Digger Bed Lift Kit
-
Sand Pans
-
Trailer Jack Kit
-
Gauge Wheels
-
Rock Traps
Call for details.
Standard 5ft Pull Type Stone Picker Features
Tongue Weight: 1,430 lbs
Weight: 4,940 lbs
Length: 22.75ft*
Height: 5.375ft
Digger Width: 5ft
Overall Width: 8ft
Bin Capacity: 1.6 Cubic Yards
*changes if conveyor is added on
Recommended Tractor Specifications:
-
80-120 Horsepower
-
15 GPM Hydraulic Flow
Key Features:
-
Fully Hydraulic
-
Instant Reversing
-
Cat 2 Hitch Option
-
Bull-pull Hitch Option
-
Adjustable Digger Bed Angle
-
Infinitely Variable Shaker Adjustment
-
Open Stone Box Bottom
7½ft Pull Type
Our 7½ft Stone Picker has a Holding Bin for field storage and is engineered to remove stones in a large area.
7-1/2ft Stone Picker
Standard 7.5ft Pull Type Stone Picker Chain
Different chain options available.
Call for details.
7.5ft Pull Type Stone
Picker Options
With Optional Unloading Conveyor
-
Unloading Conveyor
-
Hydraulic Digger Bed Lift Kit
-
Sand Pans
-
Trailer Jack Kit
-
Gauge Wheels
-
Rock Traps
Call for details.
Without Optional Unloading Conveyor
Standard 7.5ft Pull Type Stone Picker Dimensions
Tongue Weight: ~2300lbs**
Length: 24.33ft*
Height: 7.5ft*
Digger Width: 7.875ft
Overall Width: 11.5ft
Bin Capacity: 2.4 Cubic Yards
*changes if conveyor is added on
**changes depending on what size/length of chain is used.
Standard 7.5ft Pull Type Stone Picker Features
Recommended Tractor Specifications:
• 120-160Hp
• 15GPM Hydraulic Flow.
Key Features:
• Fully Hydraulic
• Instant Reversing
• Cat 3 Hitch
10ft Industrial Grade Pull Type W/ Conveyor Option
AFE also offers a 10ft industrial grade Stone Picker with a Holding Bin and an optional Unloading Conveyor to load trucks or trailers in the fields.
With Optional Unloading Conveyor
Standard 10ft Pull Type Stone Picker Chain
Different chain options available.
Call for details.
10ft Pull Type Stone
Picker Options
-
Unloading Conveyor
-
Hydraulic Digger Bed Lift Kit
-
Sand Pans
-
Trailer Jack Kit
-
Gauge Wheels
-
Rock Traps
Call for details.
Without Optional Unloading Conveyor
Standard 10ft Pull Type Stone Picker Dimensions
Standard 10ft Pull Type Stone Picker Features
10ft Stone Picker
Tongue Weight: 4,500 lbs.
Weight: 21,000 lbs.
Length: 33.813ft*
Height: 9.313ft
Digger Width: 10.792ft
Overall Width: 16.958ft
Bin Capacity w/o Conveyor: 6.7 Cubic Yards
Bin Capacity w/ Conveyor: 2.5 Cubic Yards
*changes if conveyor is added on
Recommended Tractor Specifications:
• 180Hp
• 45GPM Hydraulic Flow.
Key Features:
• Fully Hydraulic
• Instant Reversing
• Cat 3 Hitch
With Optional Unloading Conveyor
With Optional Unloading Conveyor
Without Optional Unloading Conveyor
